Pitch: 1.27 mm (0.05 in)
Wire Gauge: 30 AWG
Row Spacing: 2.54 mm (0.1 in)
Housing Color: Gray
Latching Type: Unlatched
Contact Gender: Socket (Female)
Current Rating: 750 mA
Mounting Angle: Straight
Mounting Style: Cable Mount / Free Hanging
Number of Rows: 2 Row
Voltage Rating: 500 V
Contact Plating: Gold
Contact Material: Beryllium Copper
Housing Material: Polybutylene Terephthalate (PBT)
Termination Style: IDC
Flammability Rating: UL 94 V-0
Number of Positions: 36 Position
Insulation Resistance: 1 GOhms
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 55 C
