Testing Wavelength (MM: ±20nm, SM: ±10nm): 1625nm
Dynamic Range (dB): 32dB
Event/Attenuation Dead-zone (m): 0.8/4
Size/Weight: 215x155x68mm / 1.1kg (Battery included)
Display: 7 inch touch-sensitive TFT-LCD screen with LED Backlight 800x480 TFT
Interface: 2xUSB port (Type A x 1, Type B x 1), 4 x Optical Port (1xVFL port, 1xOPM port, 2xOTDR port)
Power Supply: AC/DC adapter, 10V(dc), 100V(ac) to 240V(ac), 50~60Hz
Battery: 7.4V(dc)/2500mAh x 2pcs rechargeable lithium battery (with Air Traffic Certification)
Operating time: 12 hours1 Telcordia GR-196-CORE
Charging time: <3 hours (power off)
Power Saving: Auto Power Off- Never/1min/5min/10min/30min/60min
Data Storage: Internal memory: 16GB (about 100,000 groups of curves)
Language: Multi-language support
Environmental Conditions: Operating temperature and humidity: -10°C~+50°C, ≤95% (non-condensation), Storage temperature and humidity: -20°C~+75°C, ≤95% (non-condensation)
Accessories: Standard: Main unit, power adapter, Lithium battery, FC adapter, USB cord, User guide, CD disk, carrying case, Optional: SC/ST/LC adapter, Bare fiber adapter
OTDR Module
Pulse Width:
Single mode: 3ns, 5ns, 10ns, 20ns, 50ns, 100ns, 200ns, 500ns, 1μs, 2μs, 5μs, 10μs, 20μs
Multi-mode: 3ns, 5ns, 10ns, 20ns, 50ns, 100ns, 200ns, 500ns, 1μs, 2μs
Distance Range:
Single mode: 100m, 500m, 2km, 5km, 10km, 20km, 40km, 80km, 120km, 160km, 240km
Multi-mode: 500m, 2km, 5km, 10km, 20km, 40km
Sampling Resolution: Minimum 5cm
Sampling Point: Maximum 256.000 points
Linearity: ≤0.05dB/dB
Distance Resolution: 0.01m
Reflectance Accuracy: Single mode: ±2dB, multi-mode: ±4dB
IOR Setting: 1.2000~1.5999, 0.0001 step
Units: km, miles, kfeet
VFL Module (Visual Fault Locator)
Wavelength (±20nm): 650nm
Power: 10mw, CLASSIII B
Range: 12km
Connector: FC/UPC
Launching Mode: CW/2Hz
OPM Module (Optical Power Meter)
Wavelength Range (±20nm): 800 ~1700nm
Calibrated Wavelength: 850/1300/1310/1490/1550/1625/1650nm
Test Range: Type A: -65~+5dBm (standard); Type B: -40~+23dBm (optional)
Resolution: 0.01dB
Accuracy: ±0.35dB±1nW
Modulation Identification: 270/1k/2k Hz, P input≥-40dBm
Connector: FC/UPC
OLS Module (Optical Laser Source)
Working Wavelength (±20nm): Same as OTDR Wavelength
Output Power: -5dBm±1dB
Output Mode: CW/270/1k/2k Hz
FM Module
Magnification: 400X
Resolution: 1.0µm
View of Field: 0.40×0.31mm
Storage/working Condition: -18℃~35℃
Dimension: 235×95×30mm
Sensor: 1/3 inch 2 million of pixel
Weight: 150g
USB: 1.1/2.0
Adapter:
SC-PC-F (For SC/PC adapter)
FC-PC-F (For FC/PC adapter)
LC-PC-F (For LC/PC adapter)
2.5PC-M (For 2.5mm connector, SC/PC, FC/PC, ST/PC)
