Gain: 5.78 dBi, 4.27 dBi, 5.65 dBi
VSWR: 2
Style: Square
Width: 47 mm
Height: 14 mm
Length: 48.5 mm
Impedance: 50 Ohms
Cable Type: 5 M 2.7 mm RG174
Application: M2M, Surveillance, Fleet Management, Asset Tracking, Autonomous Driving, Telematics, Agriculture, Instrumentation
Unit Weight: 127.447 g
Cable Length: 5 mm
Polarization: RHCP
Mounting Style: Adhesive Mount
Number of Bands: 3 Band
Center Frequency: 1.561098 GHz, 1.57542 GHz, 1.602 GHz
Mechanical Style: Module
Maximum Frequency: 1.602 GHz
Minimum Frequency: 1.561 GHz
Termination Style: Connector
Protocol - Sub GHz: IoT
Antenna Connector Type: SMA Male
Protocol - GPS, GLONASS: BEIDOU, GLONASS, GNSS, GPS
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
