ACEY ACEY-5000DS 5000A Battery Pack DC Power Gantry Spot Welding Machine With Slide

Maximum Transformer Output Power: 35KVA

Maximum Output Short Circuit Current: 5000A

Floating Voltage: 10V

Control Mode: Constant current control

Cooling Mode: Forced air cooling

Condition: 8

Application: Electronic components, battery nickel plates, enameled wire, sensor wire, halogen lamps, etc.

Maximum Parallel Welding Thickness: 0.03mm–0.5mm

Maximum Upper and Lower Butt Welding Thickness: 0.3mm + 1mm

Machine Weight: 23.5kg

External Dimensions: L810mm × W610mm × H1220mm

Input Power: 3-phase AC380V±10%, 50/60Hz

ACEY-5000DS (DC machine) Battery Pack Spot Welding Machine with slide is a general platform for cylinder battery pack assembling. It equipped with advanced 5000A DC inverter welding power supply, the new upgrade installs a movable slide rail, which is more convenient to operate. Suitable battery for pack spot welding and assembly in the factory.
