ACEY ACEY-ACS-1 Automatic Cylindrical Battery Sealing Machine

Air source: 0.6～0.8MPa argon, nitrogen gas cylinder, or compressed air (compressed air is not recommended in the glove box)

Exhaust design: specially designed exhaust port, which can be connected externally through KF40 and other devices

Air consumption: about 480ml air consumption for a single seal

Sealing pressure: manual control valve control, maximum pressure 1MPa, recommended pressure 0.7MPa

Sealing stroke: 30mm

Sealing mold: standard 18650 series packaging mold, optional or additional specifications

Installation size: L290mmW205mmH330mm

Approximate weight: 27Kg

It has the function of preventing short circuit of battery sealing.

Structural material: high-strength chrome steel, the surface will never rust after environmental protection plating and spraying treatment.

1. Pure pneumatic operation, no electricity, convenient and easy to use;

2. Two-station sealing, better sealing and sealing effect;

3. Precision mold design ensures accurate and reliable sealing forming, solid steel structure design, stable and safe use.

4. Beautiful appearance, easy maintenance, small size, convenient operation, accurate molding, etc.

5. Compressed air or inert gas cylinders are used to supply air. The compressed air exhaust is connected to prevent damage to the glove box atmosphere.

6. Precision mold design ensures accurate and reliable sealing forming, solid steel structure design, stable and safe use.
