ACEY ACEY-D300B Customized Automatic Electric Double Side Weld Machine For Lithium Battery Pack

Y-axis Travel: 500mm (customizable)

X-axis Travel: 350mm (customizable)

Maximum Spot Welding Speed: 0.5s/point (about 2800 units of 18650 cells per hour)

Motor Drive Speed: 1000mm/s

Maximum Battery Cell Loading Capacity: X direction: 26; Y direction: 26

Capable File Group Storage: 100 groups

Operating System: Embedded system human-machine interface

Transmission Mode: Taiwan precision screw with guide rail

Driving Mode: Stepper servo motor

Repeat Positioning Accuracy: ±0.02mm

Dimensions: L1020mm × W910mm × H1770mm

Power: 4000W

Machine Weight: 350KG

Maximum Bearing Weight of Y-axis: 50KG

Input Power Supply: Single-phase AC380V/50Hz

Air Source: 0.4–0.6MPa

ACEY-D300B can be used in electric tool battery, torsion car battery, Energy Storage Battery Pack, Scooter Electric Vehicle Battery, etc. Compared with manual spot welding, the efficiency and accuracy of welding have been greatly improved.
