Capacity (L/min): 20
Vacuum level: -0.06～-0.095 Mpa
Working pressure: ≤ 0.4 Mpa
Temperature range: 20-80℃
Continuous work: ≥200 hr
No failure running: ≥5000 hr
Power supply: 380V, 50HZ, 3PH (or Customized)
Working noise: 65 dB
Heating power (kw): 15
Total power (kw): 16.5
Inlet/outlet(mm): 32
Weight (kg): 320
Dimension (mm) (L x W x H): 1100×800×1200 (mm)
Specifications after treatment
Item Specifications
Breakdown voltage: ≥ 50KV
Water content: ≤ 4ppm
Gas content: ≤ 0.1%
Filtering rate: ≤ 1 micron (ISO 14/12/10)
Flash point (close cup): ≥130℃
Interfacial tension performance: > 40 Dynes / cm at 25℃
Power factor performance: < 0.005 % at 25℃
