Advantech PCE-2132-00A1 Single Board Computers Q470, Compact IPC MB

Core: Celeron G5900E/G5900TE, Core i3-10100E/10100TE, Core i5-10500E/10500TE, Core i7-10700E/10700TE, Core i9-10900E/10900TE, Pentium G6400E/G6400TE

Chipsets: Q470E

Frequency: 1.8 GHz to 3.2 GHz

Dimensions: 186 mm x 127 mm

Cache Memory: 6 MB to 20 MB

Installed RAM: 0 GB

Interface Type: Audio, DP, Ethernet, HDMI, M.2, mPCIe, mSATA, RS-232/422/485, USB 2.0, USB 3.0, VGA

Processor Type: Celeron G5900E/G5900TE, Core i3-10100E/10100TE, Core i5-10500E/10500TE, Core i7-10700E/10700TE, Core i9-10900E/10900TE, Pentium G6400E/G6400TE

Number of Cores: 4 Core to 10 Core

Processor Brand: Intel

Maximum RAM Capacity: 64 GB

Maximum Operating Temperature: + 60 C

Minimum Operating Temperature: 0 C
