Direct access to our certified experts
Certification: CB, UL, CE, FCC, CCC, BSMI, C1D2
CPU: Intel® Atom® E3845 1.91GHz Quad-Core
Graphics Engine: Intel® HD Graphics
Memory: 1 x SO-DIMM with 4 GB DDR3L 1333 MHz
OS Support: Microsoft® Windows 10 2019 LTSC, WES7, Linux
Power Input: 9~36 VDC
Storage: 1 x mSATA (shared with mPCIe), 1 x 2.5\" SSD/HDD bay
Display: 1 x VGA, 1 x HDMI
Expansion: 2 x Full-size mPCIe Slot
LAN: 3 x 10/100/1000 Mbps
Power Connection: 1 x 4-Pin Terminal Block
Serial Port: 1 x RS-232, 1 x RS-422/485
USB port: 1 x USB 3.0, 2 x USB 2.0
General Digital I/O: 4-ch DI, 4-ch DO
Ingress Protection: IP40
Operating Temp.: -20~60 °C (-4~140 °F)
Humidity: 95% RH (non-condensing)
Shock: 50 G, half sine
Storage Temperature: -40~85 °C (-40~185 °F)
Vibration: 5 Grms, random
Dimension (W x H x D): 85 x 139 x 152 mm
Enclosure: Aluminum housing
Weight (net): 1.6 Kg (3.5 lb)
