Accuracy Class: ISO 376: 1
Nominal Load (Emax) : 75 kN
Relative Error (At Reading):
a) repeatability 0°-120°-240° (b): ≤ ±0.150%
b) interpolation (fc): ≤ ±0.090%
c) reversibility (u): ≤ ±0.200%
d) zero (fo): ≤ ±0.020% F.S.
Linearity: ≤ ±0.03% F.S.
Hysteresis: ≤ ±0.03% F.S.
Temperature Effect (10°C):
a) on zero: ≤ ±0.030% F.S.
b) on sensitivity: ≤ ±0.020% F.S.
Nominal Sensitivity: 2mV/V
Sensivity Tolerance: ≤ ±0.1% F.S.
Input Resistance: 700±2Ω
Output Resistance: 705±2Ω
Insulation Resistance: > 5 GΩ
Zero Balance: ≤ ± 1% F.S.
Recommended Supply Voltage: 10 V
Nominal Supply Voltage: 1-15 V
Maximum Supply Voltage: 18 V
Mechanical Limit Values:
Referred To Nominal Load::
a) service load: 120%
b) max permissible load: 150%
c) breaking load: >300%
d) max transverse load: 50%
e) max permissible dynamic load: 75%
Displacement At Nominal Load : ∼ 0.06mm
Reference Temperature: +23°C
Temperature Nominal Range: -10/+40 °C
Service Temperature: -10/+70 °C
Storage Temperature: -20/+80 °C
Weight : 2.08 kg
Protection Class (En 60529): IP67
Execution Material: Stainless Steel
Cable Length: 5m
Fixing Screws:
a) diameter: M8
b) resistance class: 12.9
c) tightening torque: 80 Nm
