Accuracy Class: OIML R60: C2
Legal Divisions : 2000
Nominal Load (Emax): 1T
Min. Verification Interval (Vmin) : Emax / 10000
Combined Error: ≤ ± 0.027 %
Non-Repeatability: ≤ ± 0.015 %
Zero Return Over 30 Min.: ≤ ± 0.021 %
Creep To Nominal Load::
a) over 30 min.: ≤ ± 0.028 %
b) over 20 and 30 min.: ≤ ± 0.012 %
Temperature Effect (10 °C):
a) on zero: ≤ ± 0.023 %
b) on sensitivity: ≤ ± 0.010 %
Nominal Sensitivity: 2 mV/V
Sensivity Tolerance: ≤ ± 0.1 %
Input Resistance: 420 ± 20 Ω
Output Resistance: 350 ± 2 Ω
Insulation Resistance: > 5 G Ω
Zero Balance: ≤ ± 1 %
Recommended Supply Voltage: 10 V
Nominal Supply Voltage: 1 - 15 V
Maximum Supply Voltage: 18 V
Mechanical Limit Values Referred To Nominal Load::
a) minimum load: 0%
b) service load: 120%
c) max permissible load: 150%
d) breaking load: > 300 %
e) max transverse load: 200%
f) max permissible dynamic load: 75%
Displacement At Nominal Load: ~ 0.4 mm
Reference Temperature: + 23 °C
Temperature Nominal Range: -10 / +40 °C
Service Temperature: -20 / +70 °C
Storage Temperature: -20 / +80 °C
Weight : ~ 1.0 kg
Protection Class (En 60529): IP67
Execution Material: Stainless Steel
Cable Length: 5m
Fixing Screws:
a) diameter: M12
b) resistance class: 12.9
c) tightening torque: 70 Nm
