Bandwidth（-3dB）: 200Hz~120kHz
Maximum output voltage: 424Vrms
Input voltage at full output: 1Vrms（1kHz）
Maximum output power: 200VA
Input resistance: 10kΩ
Current monitor: 100mV/A
Voltage monitor: 10mV/ V
Total harmonic distortion （THD）: ≤1%@1kHz，100Vp-p
Output Connector :4mm Banana socket
Fault lights: Over current
Signal Ground: Floated to the same level as the source
Supply voltage: AC220V±10%，50Hz
Operating temperature: 0℃~45℃
Storage temperature: -20℃~50℃
Humidity: ≤80%RH，no condensation
Size (W * H * D): 440*290*565mm
Output impedance: 56Ω, 224Ω, 505Ω, 898Ω
Maximum output voltage: 106Vrms, 212Vrms, 318Vrms, 424Vrms
Maximum output current: 1.89Arms, 0.95Arms, 0.63Arms, 0.47Arms
