Capacity F(nom) (N): 1000
Resolution (N ): 1
Tolerance( % F(nom) ): 0.5
Temperature coefficient (% / K): 0.02
Reproducibility (% F): 0
Repeatability (% F ): 0.3
Hysteresis( % F ): 0
Max. operating force (% F(nom)): 120
Measurement error (% F(nom)): 1
Breaking force( % F(nom)): 150
Nominal deflection (mm): 0.25
Display (Type): LCD. 5 digits. 14mm high
Measuring principle : Force sensor with full-bridge strain gauge and high-speed µ-processor
Measuring rate( Hz (Peak) ): ~ 1000
Memory : Statistics memory with display of the mean. maximum. minimum and standard deviation for 1000 measurements
Cable diameter :
mm (slot width): 0.5 | 0.8 | 1.0 | 1.3 | 1.5 | 2.0 | 2.5 | 3.0 | 3.5 | 4.0 | 5.0 | 6.0
mm (clamping device) : 0.1 - 6.0
Cross section:
Range IEC 60352-2: 0.05 - 6 mm² (AWG 8- 30)
Range SAE AS7928 II : AWG 10 - 30
Min. cable length( mm ): 70
Material : Anodised aluminum. surface hardened steel. stainless steel V2A
