Color: White
Pitch: 8 mm
Width: 16.2 mm
Height: 12.2 mm
Length: 13.2 mm
Wire Gauge: 24 AWG to 12 AWG
Thread Size: M2.6 mm
Unit Weight: 3.084 g
Current Rating: 20 A
Mounting Angle: Straight
Mounting Style: Panel Mount
Number of Rows: 2 Row
Voltage Rating: 300 V
Wire Gauge Max: 12 AWG
Wire Gauge Min: 24 AWG
Contact Plating: Tin
Contact Material: Brass
Housing Material: Polyamide (PA)
Termination Style: Screw
Flammability Rating: UL 94 V-0
Number of Positions: 2 Position
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 30 C
