Direct access to our certified experts
Resistance measurement range: 3mΩ/30mΩ/300mΩ/3Ω
Resolution: 1uΩ/10uΩ/100uΩ/1mΩ
Resistance Accuracy: 1%
Voltage measurement range: 7V/70V
Resolution: 1mV/10mV
Voltage Accuracy: 0.5%
Temperature measurement range: -10.0℃~60.0℃
Resolution: 0.1℃
Temperature Accuracy: ±1.0℃
Measurement method: 1kHz AC 4-terminal test method, open circuit terminal voltage 3V max. with a measuring current between 2.0mA and 200mA (dependent on range).
Temperature measurement: NTC temperature sensor (10K Ω at 26 ℃)
Measurement time: about 2 seconds
LCD display: 70.1mm × 52.6mm (2.75 x 2.0 inches)
Communications: USB or Bluetooth
Storage data: Up to 5000 sets of data
Power supply: DC 3.7V rechargeable lithium battery
Insulation resistance: above 20MΩ (500V between circuit and shell)
Transit Case Dimensions: 13 x 10 x 4.25 inches
Standard: IEC 61010
