Pitch: 2 mm (0.079 in)
Application: Board-to-Board
Housing Color: Black
Contact Gender: Pin (Male)
Current Rating: 2 A
Mounting Angle: Straight
Number of Rows: 2 Row
Voltage Rating: 650 V
Contact Plating: Gold
Contact Material: Copper Alloy
Housing Material: Thermoplastic (TP)
Termination Style: Solder Pin
Mating Post Length: 4.1 mm (0.161 in)
Number of Positions: 50 Position
Insulation Resistance: 1 GOhms
Termination Post Length: 3 mm (0.118 in)
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
