Pitch: 2.54 mm (0.1 in)
Application: Wire-to-Board
Housing Color: Blue
Current Rating: 3 A
Mounting Angle: Straight
Number of Rows: 2 Row
Voltage Rating: 1 kV
Contact Plating: Gold
Contact Material: Copper Alloy
Housing Material: Polybutylene Terephthalate (PBT)
Termination Style: Solder Pin
Mating Post Length: 5.8 mm (0.228 in)
Number of Positions: 40 Position
Insulation Resistance: 100 GOhms
Termination Post Length: 2.67 mm (0.105 in)
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 65 C
