Pitch: 2.54 mm (0.1 in)
Row Spacing: 2.54 mm (0.1 in)
Housing Color: Gray
Contact Gender: Pin (Male)
Current Rating: 1.5 A
Mounting Angle: Straight
Mounting Style: Mounting Flange
Number of Rows: 2 Row
Voltage Rating: 250 V
Contact Plating: Gold
Contact Material: Copper Alloy
Housing Material: Thermoplastic (TP)
Termination Style: Solder Pin
Mating Post Length: 6.5 mm (0.256 in)
Flammability Rating: UL 94 V-0
Number of Positions: 20 Position
Insulation Resistance: 5 GOhms
Termination Post Length: 4.35 mm (0.171 in)
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
