Pitch: 2 mm (0.079 in)
Application: Board-to-Board
Housing Color: Cream
Contact Gender: Pin (Male)
Current Rating: 2 A
Mounting Angle: Straight
Mounting Style: SMD/SMT
Number of Rows: 1 Row
Contact Plating: Gold
Contact Material: Copper Alloy
Housing Material: Thermoplastic (TP)
Termination Style: Solder
Mating Post Length: 4 mm (0.157 in)
Flammability Rating: UL 94 V-0
Number of Positions: 3 Position
Insulation Resistance: 1 GOhms
Termination Post Length: 2.37 mm (0.093 in)
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
