Gain: - 2.50 dBi, - 1.50 dBi, - 2.50 dBi, - 2.50 dBi, - 1.50 dBi
VSWR: 3.30 :1, 2.90 :1, 2.10 :1, 3.20 :1, 2.90 :1
Style: T-Bar Flex
Width: 20 mm
Height: 0.15 mm
Length: 80 mm
Impedance: 50 Ohms
Cable Type: 100 mm RF1.13
Technology: Cellular, LTE, MiMo
Application: Smart Meters, Femto / Pico base stations, Tracker Devices, Remote Monitoring, M2M, POS Terminals
Unit Weight: 500 mg
Cable Length: 113 mm
Polarization: Linear
Mounting Style: Adhesive Mount
Number of Bands: 6 Band
Center Frequency: 892 MHz, 1.85 GHz, 2.14 GHz, 2.35 GHz, 2.595 GHz
Mechanical Style: PCB Trace
Maximum Frequency: 2.69 GHz
Minimum Frequency: 824 MHz
Termination Style: Connector
Antenna Connector Type: IPEX MHF
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: 3G/4G, Cellular (NBIoT, LTE), GSM, DCS, PCS, WCDMA
