Input range: 220-264 Vac: 2000 W; 200-220 Vac: 1780 W; 220-320 Vdc
Frequency: 47 Hz to 63 Hz
Max input current: 10 Arms @ 200 Vac/220 Vac
Main DC Output
Nominal setting (12 V / 1 A, 12 VSB / 0.1 A): MIN: 11.9/NOM: 12.0/ MAX: 12.1
Total output regulation range: MIN: 11.4 V/ MAX: 12.6 V
Output current: MIN: 1/ MAX: 166.7 A
Standby DC Output
Nominal setting: MIN: 11.7/ NOM: 12.0/ MAX: 12.3
Total output regulation range: MIN: 11.4 V/ MAX: 12.6 V
Output current: MIN: 0 A/ MAX: 3 A
Operating temperature: 0 to 50 °C
Operating humidity: +5% to +95% non-condensing
Storage temperature: -40 °C to +70 °C, non-condensing
Storage humidity: +5% to +95% non-condensing
Airflow: Normal fan
Minimum Current: 1 A
Maximum Current: 166.7 A
Output Ripple P/P : 120 mV
Standby: 12.0 V @ 3 A
