Input
Input range: 90 - 264 Vac (wide range)
Frequency: 47 - 63 Hz, single phase AC
Output
Main DC voltage: +12 V
Standby: +3.3 Vsb
Regulation: +12 Vdc,+5%/-3% ; +3.3 Vsb, +5%/-4%
Operating temperature: -10 °C to 50 °C
Storage temperature: -40 °C to +70 °C
Humidity: 20 to 90% RH, non-condensing
Nominal Output Voltage Set Point: 12.0 Vdc; 3.3 Vsb
Set Point Tolerance: ± 0.2%; ± 1%
Total Regulation: +5/-3%; +5/-4%
Minimum Current: 0 A; 0 A
Maximum Current: 37.0 A; 3.0 A
Output Ripple P/P: 120 mV; 60 mV
Over Current: 39.5 A - 44.4 A; 4.9 A Avg, 7 A max
Options: Reverse Air
