Input range (operating): 180 - 264 Vac; 90 - 140 Vac
Nominal input: 200 Vac; 110 Vac. Input through Card Edge Connection on same end as DC output
Frequency: 47 to 63 Hz
Input current: 19 A max input current
Output rating:
48 V @ 62.0 A/ 5 Vsb @ 3.0 A: 180 - 264 Vac
48 V @ 29.4 A/ 5 Vsb @ 3.0 A: 90 - 140 Vac
Set point: 48 V
Total regulation range: 48 V ± 5%/ 5 Vsb ± 4%. Line/load/transient when measured at output connection
Rated load: 3000 W maximum @ 200 Vac Input. 1500 W maximum @ 110 Vac Input. No derating over operating temp range
Minimum load: 48 V @ 0.0 A/ 5 Vsb @ 0.0 A. No loss of regulation
Operating temperature: - 10 ° to +40 °C
Storage temperature: - 40 ° to +85 °C
Cooling: External fans with Fan Fail and Fan Speed control
Operating relative humidity: 5% to 95% non-condensing
