Input
Input range:
90 - 264 Vac (Operating)
115/230 Vac (Nominal)
TERMINAL BLOCK
Frequency: 47 - 63 Hz, Nominal 50/60
Input current: 5 Arms max input current, at 90 Vac
Output
Output rating: See table 1: 90 - 264 Vac
Rated load: 310 W (360 W for current Q and U variants). Derate linear to 50% from 50 °C to 70 °C
Minimum load: Main output @ 0.0 A; 5 Vsb @ 0.0 A. No loss of regulation
Operating temperature: -40 °C to +70 °C, linear derating to 50% from 50 °C to 70 °C
Storage temperature: -40 °C to +85 °C
Humidity: 10 to 90%, non-condensing. Operating. Conformal coat option available.
Functions: Short circuit protection; Overload protection (OCP); Overvoltage protection (OVP)
Ordering Information
Output: 50 V
Nominal Output Voltage Set Point: 48 V
Set Point Tolerance: ±0.5%
Adjustment Range: 43.0 - 60.0 V
Current
Min: 0 A
Max: 6.3 A
Output Ripple P/P (0-50°C): 480 mV
Max Continuous Power: 310 W
Combined Line/ Load Regulation: 2%
