Input voltage range: 180 to 264 Vac: 2000 W; 90 to 140 Vac: 1000 W
Frequency: 47 Hz to 63 Hz
Max input current: 11.5 Arms at 100/200 Vac
Main DC Output
Nominal setting: MIN: 12.175 /NOM: 12.2/ MAX: 12.225
Total output regulation range: MIN: 11.4 V/ MAX: 12.9 V
Output current: MIN: 5.0 A1, 2 (minimum starting load for 17% transient step)/ MAX: 163.9 A at high line; 82 A at low line
Standby DC Output
Nominal setting: MIN: 11.95/ NOM: 12/ MAX: 12.05
Total output regulation range: MIN: 11.4 V/ MAX: 12.6 V
Output current: MIN: 0.0 A/ MAX: 3.5 A
Operating temperature: 0 to 50 °C, allowable up to 60 °C at derated output of 2.6%/°C above 50 °C
Operating relative humidity: Up to 95% non-condensing
Nominal Main Output: 12.2 V @ TBD
Standby Output: 12 V @ 3.5 A
Airflow Direction: Reverse
