Resolution (H x V Pixels): 4128 x 3008 (full resolution) / 4096 x 3000 (default resolution)
Resolution: 12 MP
Sensor Type: Sony IMX545-AAQJ-C / Progressive scan CMOS / Global shutter
Sensor Format: 1/1.1 inch
Effective Sensor Diagonal: 14 mm
Pixel Size (H x V): 2.74 x 2.74 µm
Frame Rate (at Default Settings): 29.3 fps / 31.7 fps (Device Link Throughput Limit mode set to Off)
Mono / Color: Color
Image Data Interface: USB 3.0, nominal max. 5 Gbit/s (SuperSpeed)
Synchronization: Via hardware trigger / Via software trigger / Via free run
Exposure Time Control: Via hardware trigger / Programmable via the camera API
Camera Power Requirements: ≈3.2 W (typical) @ 5 VDC
I/O Lines: 1 opto-coupled input line / 2 general purpose I/O (GPIO) lines
Lens Mount: C-mount
Size (L x W x H): 36.3 x 29 x 29 mm (without lens mount or connectors) / 48.1 x 29 x 29 mm (with lens mount and connectors)
Weight: <85 g
Conformity: CE (includes RoHS), EAC, UL Listed, FCC, KC, GenICam, USB3 Vision, IP30
Software: Basler pylon Camera Software Suite (version 6.0 or higher) Available for Windows, Linux x86, Linux ARM, macOS, and Android
