Oscilloscopes:
Bandwidth: 100 MHz
Real Time Sampling Rate: 1 GSa/s (half-channel interleaved), 500 MSa/s (per channel)
Channels: 2
Max Memory Depth: 40 kpts
Vertical Resolution: 8 bit
Vertical Sensitivity: 2 mV/div – 100 V/div (1-2-5 order)
Horizontal Scan Range: 2.5 nS/div - 50 S/div
Maximum Input Voltage: 300 Vrms
I/O Interface: USB
Trigger: Edge, Pulse Width, Video*, Slope, Alternative
Math Operation: Add, Subtract, Multiply, Divide, FFT
FFT: Hanning, Hamming, Blackman, Rectangular
Measure: Vpp, Vmax, Vmin, Vamp, Vtop, Vbase, Vavg, Mean, Crms, Vrms, ROVShoot, FOVShoot, RPREShoot, FPREShoot, Rise, Fall, Freq, Prd, +Wid, -Wid, +Dut, -Dut, BWid, Phas, FRR, FRF, FFR, FFF, LRR, LRF, LFR, LFF
Multimeter:
DCV: 60.00 mV - 1000 V
ACV: 60.00 mV - 750 V
DCA, ACA: 60.00 mA - 10.00 A
R: 600.0 Ω - 60.00 MΩ
C: 40.00 nF -400.0 µF
Diode : yes
Continuity: Yes
Display: 5.7” Color TFT, 320 x 234 resolution, 64K color
Power Requirements: AC Adapter 100-240 VAC/9VDC
Battery Rating: 5000 mAh, 7.4 VDC
Dimensions: 163.2 x 259.5 x 53.3
Weight: 1.54 kg
Supplied Accessories: User manual, passive probes (one per channel), pair of DMM test leads, 7.4 V Li-ion battery BP2510, USB cable, probe compensation connector, AC power adapter
