Width: 3.75 mm
Height: 1.4 mm
Length: 6.95 mm
Resistance: 4 mOhms
Qualification: AEC-Q200
Contact Rating: 14 VDC / 8 A, 10000 cycles
Maximum Voltage: 14 VDC / 8 A, 10000 cycles
Rated Temperature: + 90 C
Reset Temperature: + 40 C
Maximum Leakage Current: 300 mA
Maximum Breaking Current: 14 VDC / 8 A, 10000 cycles
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
