MODEL

Spindle: SC4-21
Sample Chamber:* SC4-13R(P)
Sample Volume: 7.1mL
Shear Rate (sec-1): .93N

Spindle: SC4-27
Sample Chamber:* SC4-13R(P)
Sample Volume: 10.4mL
Shear Rate (sec-1): .34N

Spindle: SC4-15
Sample Chamber:* SC4-7R(P)
Sample Volume: 3.8mL
Shear Rate (sec-1): .48N

Spindle: SC4-28
Sample Chamber:* SC4-13R(P)
Sample Volume: 11.0mL
Shear Rate (sec-1): .28N

Spindle: SC4-29
Sample Chamber:* SC4-13R(P)
Sample Volume: 13.5mL
Shear Rate (sec-1): .25N

Spindle: SC4-14
Sample Chamber:* SC4-6R(P)
Sample Volume: 2.1mL
Shear Rate (sec-1): .40N

DV3TLV***

Not applicable for historical reasons. However, it is possible

DV2TLV****

to use the above spindles with any of these instruments.

DV1MLV

Digital Viscometers/Rheometers will automatically calculate

LVDVE

viscosity. Please contact Brookfield or an authorized dealer

LVT

if you require information on viscosity range.

DV3TRV***

20-500K

100-2.5M

200-5M

400-10M

500-12.5M

DV2TRV****

25-500K

125-2.5M

250-5M

500-10M

625-12.5M

DV1RV

50-170K

250-830K

500-1.7M

1K-3.3M

1.25K-4.2M

RVDVE

50-170K

250-830K

500-1.7M

1K-3.3M

1.25K-4.2M

RVT

50-100K

250-500K

500-1M

1K-2M

1.25K-2.5M

DV3THA***

40-1M

200-5M

400-10M

800-20M

1K-25M

DV2THA****

50-1M

250-5M

500-10M

1K-20M

1.25K-25M

DV1HA

100-300K

500-1.7M

1K-3.3M

2K-6.7M

2.5K-8.3M

HADVE

100-300K

500-1.7M

1K-3.3M

2K-6.7M

2.5K-8.3M

HAT

100-200K

500-1M

1K-2M

2K-4M

2.5K-5M

DV3THB***

160-4M

800-20M

1.6K-40M

3.2K-80M

4K-100M

DV2THB****

200-4M

1K-20M

2K-40M

4K-80M

5K-100M

DV1HB

400-1.3M

2K-6.7M

4K-13.3M

8K-26.7M

10K-33.3M

HBDVE

400-1.3M

2K-6.7M

4K-13.3M

8K-26.7M

10K-33.3M

HBT

400-800K

2K-4M

4K-8M

8K-16M

10K-20M

Brochure

Operating instruction

Brookfield Small Sample Adapter (with spindle and chamber)
