Color Measurement
Color Geometry: 45°c:0°
Sample Port: 25 mm diameter
Spectral Range Colorimetric: 400 - 700 mm, 10 nm resolution
Repeatability Color: 0.01 ΔE94 (10 readings on white)
Reproducibility Color: 0.1 ΔE94 (average of 12 BCRA tiles)
Color Systems: CIELab/Ch, Lab(h), XYZ, Yxy
Color Indices: YI E313, YI D1925, WI E313, WI CIE, WI Berger, Opacity, Metamerism, Grayscale
Illuminants: A, C, D50, D55, D65, D75, F2, F6, F7, F8, F10, F11, UL30
Observer: 2°, 10°
Gloss Measurement
Gloss Geometry: 60°
Gloss Aperture: 25 x 15 mm
Measurement Range Gloss: 0 - 100 GU
Repeatability:
0-20 GU: ± 0.1 GU
20-100 GU: ± 0.2 GU
Reproducibility
0-20 GU: ± 0.2 GU
20-100 GU: ± 1.0 GU
3D Structure
Aperture_Size: 15 x 15 mm
Measuring Range: Cs: 0-255 mm; Ca: 2 µm - 2 mm (perceived)
Spatial Resolution: 60 µm
Height Resolution: 1-2 µm
Repeatability: 2% (10 readings on structure reference standard)
Reproducibility: 5% (on structure reference standard)
2D Reflectivity
Aperture_Size: 15 x 15 mm
Measuring Range: 0-500 000, technical performance guaranteed within 0-2500
Spatial Resolution: 60 µm
Repeatability: 0.5% (10 readings on structure reference standard)
Reproducibility: 1% (on structure reference standard)
General
Memory: 3000 samples with images, 10000 samples without images
Interface: USB Type-C (USB 3.1)
Display: 3.5" Color Touchscreen
Languages: English, German, French, Italian, Spanish, Russian, Japanese, Chinese
Power supply: Internal rechargeable battery 7.2 V
Power supply: 100 - 240 V, 50/60 Hz
Weight: 1.5 kg
Weight: 3.4 lb
Operating temperature: 10 - 40 °C
Storing temperature: 0 - 60 °C
Operating temperature: 50 - 104 °F
Storing temperature: 32 - 140 °F
Relative humidity: up to 85 % at 35 °C (95 °F), non-condensing
Dimensions: L x W x H: 15 x 24 x 15.5 cm
Dimensions: L x W x H: 5.9 x 9.5 x 6.1 in
