Function: Max Range - Basic Accuracy
Voltage DC: 600V ; ±(0.5%+1d)
Voltage AC: 600V ; ±(1.5%+2d)
Current DC: 200A ; ±(2.0%+5d)
Current AC: 200A ; ±(2.5%+4d)
Resistance: 20MΩ ; ±(3.0%+5d)
Temperature: 1000℃/1832℉ ; ±(3.0%+3d)
Continuity check: Buzzer sounds at 50Ω
Diode test: Test current 0.3mA
Size (H x W x D): 230mm x 76mm x 40mm
Weight: 315g
Accessories: Test leads, gift box with carrying case, Temperature probe and 9V battery. USB cable and Software (356W)
Datasheet
Features | |||||
| 380 | 380B | 381 | 382 | 383 |
Current measurement | AC | AC | AC | AC/DC | AC/DC |
LCD display counts | 2000 | 2000 | 4000 | 2000 | 4000 |
Data Hold | * | * | * | * | * |
REL(Zero) Function | MAX | * | * | ||
Auto Power Off | * | * | * | * | * |
Low battery indication | * | * | * | * | * |
1.2"(30mm) Jaw opening | * | * | * | * | * |
NCV Detection | * | * | * | * | |
Flashlight | * | * | * | * |
Specifications | |||||||
Function | Max. Range | Basic Accuracy | 380 | 380B | 381 | 382 | 383 |
Voltage DC | 600V | ±(0.5%+1d) | * | * | * | * | * |
Voltage AC | 600V | ±(1.5%+2d) | * | * | * | * | * |
Current DC | 400A | ±(2.0%+5d) | 200A | * | |||
Current AC | 400A | ±(2.5%+4d) | * | * | * | 200A | * |
Resistance | 40MΩ | ±(3.0%+5d) | 20MΩ | * | * | 20MΩ | * |
Temperature | 1000℃/1832℉ | ±(3.0%+3d) | * | * | * | * | * |
Capacitance | 100uF | ±(2.5%+5d) | * | * | * | ||
Frequency | 10MHz | ±(1.2%+2d) | * | 10kHz | 10kHz | ||
Continuity check | Buzzer sounds at 50Ω | ||||||
Diode test | Test current 0.3mA | ||||||
