Function: Max Range - Basic Accuracy - Max. Resolution
AC Current: 2000 A ; ±(2.5%+5d) ; 100mA
DC Current: 2000 A ; ±(2.5%+5d) ; 100mA
AC Voltage: 1000V ; ±(1.0%+4d) ; 0.1mV
DC Voltage: 1000V ; ±(0.5%+4d) ; 0.1mV
Resistance: 40MΩ ; ±(1.0%+2d) ; 0.1Ω
Frequency: 10MHz ; ±(1.2%+2d) ; 0.001Hz
Size (H x W x D): 270mm x 107mm x 50mm
Weight: 554g
Accessories: Test leads, gift box with carrying case, 9V battery.
Datasheet
Features | DT-3310 | DT-3311 | DT-3312 | DT-3316 |
Current measurements | AC | AC | AC | AC/DC |
Digital display counts | 4000 | 4000 | 4000 | 4000 |
Electronic overload protection | * | * | * | * |
Continuity buzzer & Diode check | * | * | * | * |
Data Hold function | * | * | * | * |
Peak Hold | * | |||
DCA Zero function | * | * | ||
Auto Power Off | * | * | * | * |
Low battery indication | * | * | * | * |
Display with backlight | * | * | * | * |
2.16” (55mm) Clamp jaw opening | * | * | * | * |
Specifications | |||||||
Function | Max Range | Basic Accuracy | Max. Resolution | DT-3310 | DT-3311 | DT-3312 | DT-3316 |
AC Current | 2000 A | ±(2.5%+5d) | 100mA | 1000A | 1000A | * | * |
DC Current | 2000 A | ±(2.5%+5d) | 100mA | * | |||
AC Voltage | 1000V | ±(1.0%+4d) | 0.1mV | * | * | * | * |
DC Voltage | 1000V | ±(0.5%+4d) | 0.1mV | * | * | * | * |
Resistance | 40MΩ | ±(1.0%+2d) | 0.1Ω | * | * | * | * |
Frequency | 10MHz | ±(1.2%+2d) | 0.001Hz | * | * | * | * |
Capacitance | 40mF | ±(3.0%+5d) | 0.01nF | * | * | ||
