CEM DT-3366 AC Clamp Meters (AC 1000A)

AC Current (Max Range; Basic Accuracy; Max Resolution): 1000A; ±(2.5%+5d); 10mA

AC Voltage (Max Range; Basic Accuracy; Max Resolution): 600V; ±(0.8%+2d); 0.1mV

DC Voltage (Max Range; Basic Accuracy; Max Resolution): 600V; ±(1.0%+4d); 0.1mV

Resistance (Max Range; Basic Accuracy; Max Resolution): 66MΩ; ±(1.0%+4d); 0.1Ω

Capacitance (Max Range; Basic Accuracy; Max Resolution): 40mF; ±(3.0%+5d); 0.01nF

Frequency (Max Range; Basic Accuracy; Max Resolution): 10kHz; ±(1.2%+3d); 0.01MHz

Duty Cycle (Max Range; Basic Accuracy; Max Resolution): 99.9%; ±(1.2%+3d); 0.1%

Temperature (Max Range; Basic Accuracy; Max Resolution): 1000°C/1832°F; ±(3.0%+5d); 1°C/°F

Inrush current (Max Range; Basic Accuracy; Max Resolution): 1000A; 0.1A; ±(2.0%+5d)

Continuity check: Threshold 40Ω, test current <0.5mA

Diode test: Test current of 0.3mA typical, open circuit voltage <3V DC typical

Accessories:

Test leads, gift box with carrying case, 9V battery, temperature probe

Datasheet
