CEM DT-9332 Electrical Testers (LCD 6V~1000V AC/DC)
LCD
Voltage range: 6V to 1000V ac/dc
Resolution: ±1V
Tolerance: ±(3%rdg + 5digits)
Frequency range: 0/40Hz to 400 Hz
Response time: ≤1 seconds
Auto power on: ≥6V ac/dc
Voltage detection: Automatic
Polarity detection: Full range
Range detection: Automatic
Internal basic load impedance Peak current: Maximum 3.5mA at 1000 V 200 kΩ/1s<3.5mA (no RCD tripping)
Operation time: Duration Time = 30 seconds
Recovery time: Recovery Time =240 seconds
Switchable Load: ﹣7 kΩ
Peak current: Is(load) = 150mA
RCD triping: I = 30mA at 230V
Continuity Test: 0 to 400kΩ
Accuracy: nominal resistance ﹢50%
Test current: ≤5 μ A
Single-pole Phase Test: 100V ac to 1000V ac
Frequency range: 50Hz to 400Hz
Rotary Field Indication
Voltage range(LEDs): 100V to 1000V (phase to earth)
Frequency range: 50 Hz to 60Hz
Resistance Measurement: 0Ω to 1999Ω
Resolution: 1Ω
Tolerance: ±(5%rdg + 10 digits) at 20℃
Temperature coefficient: ±5 digits/10K
Test current: ≤30μA
Size (HxWxD): 240mm x 73mm x 34mm
Weight: 237g
Accessories:
Two “AAA” batteries, gift box with carrying case.
Datasheet
Features | |||
| 9330 | 9331 | 9332 |
Complies with EN 61243-3: 2014 | * | * | * |
LED Indication Range: 12V to 1000 V dC and ac | * | * | |
Independent EIV indicator LED, indicates if >50V ac/120V dc is present even in the event of no battery power of main circuit failure. | * | * | * |
LCD Indication Range: 6V to 1000V dc and ac | * | * | |
Resistance Measurement: LCD 3%½ digit(0 to 1999 Ω/1Ω resolution) | * | * | |
LCD Backlight Display HOLD: Freeze/unfreeze display with voltage or resistance measurement | * | * | |
Rugged, Double-Insulated Wire | * | * | * |
Fixed Impedance ﹣200 kΩ(≤3.5 Ma @ 1000V) | * | * | * |
Switchable Load by 2 pushbuttons(30 mA @ 230V) | * | * | * |
Vibration During Lpad(when 2 switchable load pushbuttons are pushed) | * | * | * |
Single-Pole Phase Test(also operates with gloves) | * | * | * |
Rotary Filed Direction(also operates with gloves) | * | * | * |
Continuity Test/Diode Test | * | * | * |
Fashlight | * | * | * |
Beeper for Continuity/Phase/ACV | * | * | * |
19mm Probe Tip distance when docked | * | * | * |
CAT Ⅲ 1000V/CAT Ⅳ 600V | * | * | * |
IP64 rating | * | * | * |
