Modulation Frequency Range: 10MH z ～ 20 GHz
Frequency Accuracy: ±1×10^ -7
Frequency Resolution: 1 Hz
Working Wavelength: 1310±20nm , 1550±20nm
Average Output Optical Power Range: -2 dBm~+4 dBm
Maximum Safe Average Input Power: Input 1 : +7dBm / Input 2 : +17dBm
Average Output Optical Power Accuracy: ±0.5 dB
Average Input Optical Power Measurement Range: -35dBm~+5dBm (optical input 1 ) / -25dBm~+15dBm ( optical input 2 )
Average Input Optical Power Measurement Accuracy: ±0.5 dB
Relative Frequency Response Accuracy: ± 0.7 dB
Absolute Frequency Response Accuracy :± 1.8 dB
Frequency Response Repeatability: ± 0.3 dB
Group Delay Measurement Accuracy: ± 13 ps
Phase Measurement Accuracy: ± 3.5 º
Maximum Weight: 56 kg
Dimensions: Width high depth = 421mm × 400mm × 600mm (excluding feet, hands)
Maximum Power Consumption: 600 W
