Frequency Range: 10 MHz ~ 40GHz
Frequency Reference Accuracy : < ±0.2ppm (23°C±3°C)
Frequency Tuning Accuracy
• 10MHz – 4GHz: < ±(Reference frequency error +100kHz)
• 4GHz – 18/26.5/40/50GHz: < ±(Reference frequency error +400kHz)
Noise Figure Measurement Range: 0 – 30dB (ENR: 12dB – 17dB)
Noise Figure Measurement Uncertainty: < ±0.1dB
Gain Measurement Range: -20dB to +40dB
Gain Measurement Uncertainty : < ±0.17dB
Input VSWR
• 10MHz ≤ f ≤ 4GHz: < 1.90:1
• 4GHz < f ≤ 18GHz: < 2.10:1
• 18GHz < f ≤ 50GHz: < 2.40:1
Main Unit’s Self Noise Figure
• 10MHz ≤ f ≤ 4GHz: < 8.0dB
• 4GHz < f ≤ 18GHz: < 7.5dB
• 18GHz < f ≤ 26.5GHz: < 8.0dB
• 26.5GHz < f ≤ 40GHz: < 10.0dB
• 40GHz < f ≤ 50GHz: < 12.0dB
Jitter (Uneven): < 0.17dB (Y Factor typical value 5dB)
Noise Source Drive Voltage
• Noise source off: < 1.0 V
• Noise source on: +28.0 ± 0.10 V
Altitude Range: 4. 600 meters
RF Input Connector: 2.4mm (male), 50Ω impedance
Noise Source Drive Output
• Standard noise source: BNC (female)
• Smart noise source: multi-core connector
Power Supply: AC 100V – 240V, 50/60Hz
Power Consumption
• Max. power consumption: 250W
• Max. standby: 20W
Monitor: 10.1 inch 1280×800 HD screen, XGA
Data Storage: 160 G solid state disk, support USB 2.0 standard storage units
Dimension
• 426 (W) × 177 (H) × 460 (D) mm (excluding handle, bottom, pad and side strap)
• 510 (W) × 190 (H) × 534 (D) mm (including handle, bottom, pad and side strap)
Weight: < 23kg
See more detail information in the Datasheet
