CHROMA 63202A-150-200 Programmable DC Electronic Load (2000W)

- Voltage: 0–150V

- Current: 0–20A, 0–200A, 0–200A

- Power: 0–2000W

Static Mode

+ Minimum operating voltage (DC): 18V @ 200A

+ Constant Current (CC) mode

Range: 0–20A, 0–100A, 0–200A

Accuracy: 0.05% + 0.05% F.S.

+ Constant Resistance (CR) mode

Range: 0.015Ω–150Ω (16V/2kW); 0.06Ω–600Ω (80V/2kW); 1.5Ω–3000Ω (150V/2kW)

Accuracy: Vin/Rset (0.2%) + 0.2% I F.S.*

+ Constant Voltage (CV) mode

Range: 0–16V, 0–80V, 0–150V

Accuracy: 0.025% + 0.025% F.S.

+ Constant Power (CP) mode

Range: 0–200W, 0–1000W, 0–2000W

Accuracy: 0.2% + 0.2% F.S.

Dynamic Mode

+ Current slew rate: 0.2mA/µs–2A/µs; 1mA/µs–7A/µs; 2mA/µs–14A/µs

+ Resolution: 0.2mA/µs; 1mA/µs; 2mA/µs

+ Accuracy: 5% ± 10µs

Other

+ Power consumption: 160VA (max)

+ Dimensions (H x W x D): 132.5 x 428 x 647 mm / 5.22 x 16.85 x 25.47 inch

+ Weight: 30 kg / 66 lbs

Interface

+ Standard: Front USB (Host), Rear USB (Device)

+ Optional: Ethernet / LXI, GPIB, CAN BUS

+ System bus: Master/Slave

General Specifications

+ Operating temperature: 0°C to 40°C

+ Storage temperature: -20°C to 80°C

+ Power supply: 100–240 VAC / 47–63 Hz

+ Standard accessories: Main unit
