Max. Capacity: 5kN
Units: Force: gf, kgf, lbf, N, kN, ozf, tonf(SI), ton(long), tonf(short); Pressure: Kpa, Mpa, psi, bar, mm-Aq, mm-Hg
Force Resolution: 31 bits
Force Precision: 1/100,000
Test stroke: 400 mm (w/o grip)
Stroke resolution: 0.0001 mm
Space between columns: Ø70mm
Speed range: 0.2 ~ 1000 mm/min (Can be set by computer digital)
PC-Port:RJ45(TCP/IP) [software optional]
Data sampling rate:400Hz (Max.)
Motor type: Servo Moto
Power Supply:Single phase 200 ~ 240VAC，5A
Dimension: 50 x 53x 100cm
Weight: 65 kg
Option:
- Display panel: EM2FTP-001 or Software: SM1F0-04 or all (nessesary)
- Long extensometerQC-557
- Grips (nessesary)
