Max. Capacity: 5kN
Units: Force: gf, kgf, lbf, N, kN, ozf, tonf(SI), ton(long), tonf(short); Pressure: Kpa, Mpa, psi, bar, mm-Aq, mm-Hg
Force resolution: 23 bits
Force Precision: 1/100,000
Test troke: 800 mm (excluding grips)
Stroke resolution: 0.0125mm
Speed range: 8 ~ 550 mm/min (adjustable)
PC-Port: RJ45(TCP/IP)
Data sampling: Maximum 400 Hz
Hardware Safety Protection: Up and down limit & Emergency Stop Button Protection
Motor type: Servo Motor
Power Supply: Single phase 200 ~ 240VAC，5A
Dimension: 50× 53 × 145 cm
Weight: 80 kg
Option:
- Display panel: EM2FTP-001 or Software: SM2F0-04 or all (nessesary)
- Long extensometerQC-557
- Grips (nessesary)
