Size:From: 5-50kN
Test of drive:Electric
Piston stroke:76-450mm
Adjustment way of the cross-head:300mm
Testing room height:800mm
Inner width of test frame:440mm
Specimens:Standard test pieces, components and parts in the destructive and non-destructive test range
Application: Static and dynamic tensile and compression tests, Dynamic strength testing, Cyclic testing, service load simulations
Force measurement: Strain gauge for tensile and compressive forces. Optional assembly at the piston rod or at the base plate.
Digital control system:Control station RS-C30; 24-bit digital controller DIGIMAXX C-30®
Software:ProteusMT test software, the user-friendly operating surface for programming, execution and evaluation of static and dynamic tests
Voltage:3x400 Voltage, 50Hz
Dimension:747 x 780 x 1879/2595 mm (W x Dx H)
Optional accessories: Hydraulic aggregate, Broad range of specimen holders, tensioning equipment, compression plates and bending tables,T-slot table, Transport devices, Climate chambers, Protective equipment, Hydraulically or electromechanically adjustable lifting cylinders for the cross-head adjustment.
