Focal Length: 55mm
Magnification: 0.057X - 0.5X
Max. Image Format: 8.8mm x 6.6mm (φ11mm)
Operation Range: Iris F3.0 ‐ F22C; Focus 0.14m ‐ 1m
Control: Iris: Manual; Focus: Manual
Object Dimension at M.O.D.: 17.4mm(H) x 13.1mm(V) 2/3"
Relative illumination: 94% (at 0.057X), 81% (at 0.5X)
Effective Lens Aperture: Front (φ30.8mm); Rear (φ10.7mm)
Distortion: 2/3type, 0.5% at 0.057X(y=5.5), 0.6% at 0.5X(y=5.5)
Back Focal Length: 17.0mm
Flange Back Length: 17.526mm
Mount: C-Mount
Filter Size: M46.0 P=0.75mm
Dimensions: φ59mm x 93.1mm
Weight: 400g
Operating Temperature: -10℃ ‐ +50℃
