Temperature range: -70 to 180 ℃
JTM K09
Temperature/humidity fluctuation (100.0℃ or lower): ±0.3 ℃/%RH
Temperature/humidity fluctuation (100.1℃ or higher): ±0.5 ℃
Temperature/humidity gradient (100.0℃ or lower): 3.0 ℃/%RH
Temperature/humidity gradient (100.1℃ or higher): 5.0 ℃
Spatial temperature/humidity deviation (100.0℃ or lower): 2.0 ℃/%RH
Spatial temperature/humidity deviation (100.1℃ or higher): 3.0 ℃
Temperature change rate (Drop): 18.0 ℃/ min. (155℃ to -45℃)
Temperature change rate (Rise): 23.0 ℃/ min. (-45℃ to 155℃)
Time to reach temperature extreme (Drop): Within 10 min. (20℃ to -70℃)
Time to reach temperature extreme (Rise): Within 10 min. (20℃ to 180℃)
Testing chamber volume (L(mm)): 235 (Width 630 x Depth 540 x Height 690)
Product dimensions (mm): Width 1,100 × Depth 1,600 × Height 1,950
Exterior coating color: Cold-rolled steel plate: Dark gray
Cooling method: Mechanical single-stage compression refrigeration and dual refrigeration
Refrigerant: Single-stage side: R449A, Dual high/low-temperature side: R449A/R473A
Controller: Operation modes: Set-point or program operation (Steps: 20 per pattern, Repetitions: Max. 98 and infinite)
Safeguards: Electrical earth leakage circuit breaker, fuses, overload safeguard, high-voltage shutdown system, excess temperature increase prevention system, empty heating prevention system, etc.
Equipment: Cable hole, casters, level adjusters, and sample temperature sensor connector
Accessories: Sample shelf, shelf support, fuse, Y strainer, and instruction manual
Coolant Volume (coolant inlet temperature 32℃): 6,000 L/h
Coolant Water pressure: 0.1 to 0.5 MPa
Coolant Piping diameter (system side): Rc1 1/4
Power supply: Three-phase 200V 50/60Hz, Three-phase 220V 60Hz, Three-phase 380V 50Hz
Maximum load current: 114 A
Product weight: 850 kg
