Acoustic Parameters
Mic Array: 64 channels
Frequency: 2k – 65k Hz
SPL: 28 – 132 dB
Dynamic Range: Up to 12 dB
Distance: 0.3 – 120 m
Camera
FOV: 66° (H) × 52° (V)
Resolution: 5M pixels
Focal Length: 2.26 mm
Autofocus: Yes
LED Light: Yes
Display
Resolution: 800 × 480
Size: 4.3 inches
Screen: Capacitive touchscreen
Brightness: Max 400 nits, adjustable
Storage
Storage Capacity: 32 GB (internal)
Storage Format: .jpg (picture), .mp4 (video), .wav (audio), .cdat (data)
Video Length: Maximum 5 minutes
Data Export: USB-C and Wi-Fi
Basic Parameters
Size: 150 × 83 × 27.5 mm
Weight: 270 g
Wi-Fi: 802.11a/b/g/n/ac
Bluetooth: BT 5.2
Battery
Battery: 3.85 V, 3900 mAh
Power Supply: 9 V DC / 1 A (Charging via USB-C)
Battery Operating Time: Up to 4 hours
Environmental
IP Rate: IP54
Operating Temperature: -10 – +50 °C
Storage Temperature: -20 – +55 °C
Operating Humidity: 10 – 95 % non-condensing
Software Features
Sound visualization and localization
Gas leak detection
Partial discharge detection
Photos and videos recording
Hardware Ports: USB-C: 1 × USB 3.0 for charging, HDMI, data export, and headphone output
Language: English, Chinese, Japanese
