Max.Capacity (kgf): 1
Rated output ( mV/V): 0.5 (Approx)
Zero balance ( mV/V): 0.0±0.1
Combined error (%): 2.0
Repeatability (%): 1.0
Creep (30 min.) (%): 1.0
Temperature effec on
+ Zero value (%/℃ ): 0.5
+ Output value (%/℃ ): 0.5
Excitation
+ Recommend (V ): 5
+ Maximum ( V): 10
Resistance ():
+ Input (Ω ): 350±3.5
+ Output ( Ω): 350±3.5
Insulation ( ㏁): ＞2000 @50V DC
Compensated temp.range (℃): -10~+40
Operating temp, ( ℃ ): -20~+80
