Bandwidth(-3dB): 100MHz
Rise time: ≤3.5ns
Accuracy: ±2%
Range selection (Attenuation rate): 10X/100X
Maximum differential voltage(DC + Peak AC): 10X (±70V); 100X (±700V)
Common mode voltage (Vp) (DC + Peak AC): ±700V
Maximum input voltage-to-earth (Vrms): 450V CATII; 600V CATI*
Input impedance:
Single-ended to ground: 2.5MΩ
Between inputs: 5MΩ
Input capacitance:
Single-ended to ground: ＜4pF
Between inputs: ＜2pF
CMRR:
DC: >80dB
100kHz: >60dB
1MHz: >50dB
Noise(Vrms): 10X (<25mV); 100X (<120mV)
Differential overvoltage detection level: 10X (≥70V); 100X (≥700V)
Propagation time:
Probe: 10X (8.7ns); 100X (8.1ns)
BNC Line(1m): about 5ns
Bandwidth limit filters (5MHz): ≥-3dB@5MHz
Overload indicator (red light): Yes
Overload alarm: Yes(Can shut up manually)
Automatic save: Yes
Offset setting function: Yes（ Set in test mode）
Terminate load: ≥100kΩ
Power supply: USB 5V/1A adapter
Safety standard: IEC/EN 61010-031:2015 + AMD1:2018
EMC standard: EN61326-1:2013 EN61000-3-2:2006+A1:2009+A2:2009 EN61000-3-3:2013
