Attenuation ratio: 10:1
Bandwidth: DC to 500MHz
Rise time: 0.7ns
Input resistance: 10MΩ when used with oscilloscopes which have 1MΩ input
Input capacitance: approx.11pF
Compensation range: 8-20pF
Max.Input voltage: measurement category I: 500Vrms; Measurement Category II: 400Vrms
Pollution degree: Pollution degree 2
Operating altitude: up to 3000 meters
Max.Operating Temp: 0°C - 50°C
Humidity:
5% to 95% RH (10°C-30°C)
5% to 75% RH (30°C-40°C)
5% to 50% RH (above 40°C)
RH not controlled below 10°C
Cable length: 1.2 meter
