D-MEI DY-HT1MA Low temperature surface source blackbody furnace (-20℃~80℃)

Temperature Range: -20℃~80℃

Control Mode: Touch Screen

Temperature Resolution: 0.1℃/0.01℃

Temperature Control: PID Automatic Control

Radiating Surface: φ100mm

Emissivity: ≥0.95

Temperature Stability

Not greater than 0.15℃ and 0.15%T(bigger one in two)

T is the radiation source temperature（Within 10min）

Temperature Uniformity: Not more than the larger of 0.2℃ and 0.2%t, where t is the radiation source temperature (in the 2/3 area)

Power Supply: 220V AC 50/60Hz

Wire Line Diameter: ≥1.5㎡

Power: 500W

Dimension(L×W×H): 315mm×200mm×340mm

Weight: 10Kg

Environment: 22℃±3℃;15%-65%RH;

Optional Features

Support 232 communication

Adjustable emissivity（Adjustable between 0.95~0.99）
