Maxinmum working pressure: 7 / 8 / 10 / 12.5 bar(g) ( equivalent to 102 / 116 / 145 / 181 psig
Capacity(FAD):
8.26-21.0 m³/min ( 292-742 cfm)
8.08-20.24 m³/min (286-715 cfm)
6.83-17.15 m³/min (241-606 cfm)
5.45-14.82 m³/min (193-523 cfm)
Installed motor power: 110 kW; 150 hp
IP Grade: IP55
Noise level db(A): 73
Dimensions(mm) LxWxH: 2435*1795*1715
Weight (kg): 2310
Air outlet pipe diamete: DN80
Starting Method: Direct Driven; Air Cooling
EEI: EEI1
*) FAD in accordance with ISO 1217 : 2009, Annex C: Absolute intake pressure 1 bar (a), cooling and air intake temperature 20°C
**) Noise level as per ISO 2151 and the basic standard ISO 9614-2, operation at maximum operating pressure and maximum speed; tolerance: ± 3 dB(A) change without notice.
Specifications are subject to change without notice.
