Maxinmum working pressure: 7 / 8 / 10 / 12.5 bar(g) ( equivalent to 102 / 116 / 145 / 181 psig)
Capacity(FAD):
35.50-88.85 m³/min (1255-3137 cfm)
35.00-87.05 m³/min (1237-3074 cfm)
30.00-74.80 m³/min (1060-2641 cfm)
24.00-66.94 m³/min ( 848-2364 cfm)
Installed motor power: 400kW; 550 hp
IP Grade: IP55
Noise level db(A): 85
Dimensions(mm) LxWxH: 4500x2500x2750
Weight (kg): 9240
Air outlet pipe diamete: DN125
Starting Method: Direct Driven; W-Water Cooling
EEI: EEI1
*) FAD in accordance with ISO 1217 : 2009, Annex C: Absolute intake pressure 1 bar (a), cooling and air intake temperature 20°C
**) Noise level as per ISO 2151 and the basic standard ISO 9614-2, operation at maximum operating pressure and maximum speed; tolerance: ± 3 dB(A) change without notice.
Specifications are subject to change without notice.
