Maxinmum working pressure: 7.5 / 8.5 / 10.5 / 13 bar(g) ( equivalent to 109 / 123 / 152 / 189 psig )
Capacity(FAD)*:
50Hz (Min-Max): 3.17-5.28 / 3.16-5.26 / 3.13-5.21 / 2.07-3.45 m³/min ( equivalent to 112-187 / 112-186 / 110-184 / 73-122 cfm )
60Hz (Min-Max) : 2.69-4.49 / 2.68-4.48 / 2.67-4.47 / 2.15-3.58 m³/min ( equivalent to 95-159 / 94-158 / 94-158 / 76-126 m³/min )
Installed motor power: 30kW; 40 hp
driving mode & Cooling method: Direct Driven; Air Cooling
Noise level ** (dBA): 66
Dimensions(mm) LxWxH: 1400x900x1200
Weight (kg): 685
Air outlet pipe diamete: R1-1/2"
*) FAD in accordance with ISO 1217 : 2009, Annex C: Absolute intake pressure 1 bar (a), cooling and air intake temperature 20°C
**) Noise level as per ISO 2151 and the basic standard ISO 9614-2, operation at maximum operating pressure and maximum speed; tolerance: ± 3 dB(A) change without notice.
***) EEI 2- Energy Effiency Index 2, which refers to normal energy saving series
Specifications are subject to change without notice.
